| Model # | Description | Length | Width | Height | Ship Wt.(lbs) |
|---|---|---|---|---|---|
| 2-BCM | 2-12x20 Pan Capacity | 32" | 28" | 36" | 320 |
| 3-BCM | 3-12x20 Pan Capacity | 46" | 28" | 36" | 360 |
| 4-BCM | 4-12x20 Pan Capacity | 60" | 28" | 36" | 405 |
| 5-BCM | 5-12x20 Pan Capacity | 74" | 28" | 36" | 440 |
| 6-BCM | 6-12x20 Pan Capacity | 88" | 28" | 36" | 480 |
The Piper Elite 500 Bloomington mechanically refrigerated, extra deep well unit is listed NSF/ANSI Standard 7. Food is recessed on easily removable rails in the pan for maximum cooling efficiency without the use of ice and is ideal as a salad bar merchandiser. Elite 500 units are compatible and will interlock with other Elite 500 units.
STANDARD FEATURES
- 14-gauge stainless steel top with 1-1/2” turndown on all sides
- Top secured by four recessed bolts for easy access
- 14-gauge stainless steel legs
- 18-gauge stainless steel bottom shelf
- 20-gauge stainless steel end and front panels are attached to legs
- 20-gauge stainless steel fully welded 9-7/16” deep well
- Welded watertight well has concealed continuous refrigerated coil bonded to the sides and is fully insulated
- Cold pan has a 1” drain with shut off valve located below the unit on operator’s left side. Valve is 3/4" FTP.
- Sliding doors
- Louvered panels for ventilation of condensing unit
- End louver panel removable to access compressor
- 5” diameter swivel plate casters, 2 with brakes
- Interlocking mechanism is provided to interlock with other Elite 500 units
*30" height is available on Petite Elite units
NSF/ANSI STANDARD 7
This unit is listed with CSA in NSF/ANSI Standard 7 for design and construction and has been performance tested for the storage of potentially hazardous foods. The performance test criteria is holding a food-like media at or below 41°F without any freezing for four hours at 86°F ambient temperature.
ELECTRICAL
- 120 volts single-phase
- Eight foot electrical cord with NEMA 5-15P plug
- On/Off switch and pilot light mounted on control panel of unit's operator side
REFRIGERATION SYSTEM
- 1/3 horsepower compressor
- Fan-cooled condensing unit with an expansion valve pressure control switch
- Refrigerant coils shall be of copper tubing wrapped around the sides of the well
WARRANTY
AVAILABLE OPTIONS
| Model # | Description |
|---|---|
| 3BTS | 3-Bar Tray Slide 12.75" wide w/hinged brackets |
| BDD | Buffet double display two-sided protector guard |
| BPG | Buffet double side protector guard (no heat or lights) |
| BPG1 | Buffet single side protector guard (no heat or lights) |
| BPG1C | Buffet Style Classic Single Sided protector guard |
| BPG1FL | Buffet single side protector guard with fluorescent lights |
| BPG1IL | Buffet single side protector guard with incandescent lights |
| BPGC | Classic protector guards |
| BPGFL | Buffet double side protector guard with fluorescent lights |
| BPGH | Buffet double side protector guard with heat strip |
| BPGIL | Buffet double side protector guard with incandescent lights |
| CDD | Cafeteria double display (no heat or lights) |
| CDDC | Cafeteria Style Classic double protector guards |
| CDDL | Cafeteria double display with fluorescent lights |
| CEG | Cafeteria end guards, right or left |
| CPG | Cafeteria protector guard (no heat or lights) |
| CPGC | Cafeteria Style Classic Single protector guard |
| CPGFL | Cafeteria protector guard with fluorescent lights |
| CPGHL | Cafeteria protector guard with heat and lights |
| CPGL | Cafeteria protector guard with incandescent lights |
| CUT | Cut out for drop in dispensers |
| DOUT | Duplex Outlet (120V, 15 AMP) |
| FB | False bottom |
| FRMA | Formica Laminate Without Doors |
| HD | Hinged doors with solid bottom |
| MBS | 18" maple end bread shelf; left, right - flush with top |
| MCB | Cutting Board Maple - 8" wide w/hinged brackets |
| PPC | Pizzazz Powder Coating |
| SBS | 18" stainless steel end bread shelf; left, right - flush with top |
| SBT | Stainless steel salad bar template |
| SCB | Cutting Board Stainless - 8" wide w/hinged brackets |
| SCPGC | Cafeteria Style Classic Single protector guards |
| SKR | Skirting |
| SRTS | Solid 3-ribbed tray slide, 16-gauge stainless steel |
| SSL | Legs in lieu of casters |
| UCR-1 | Refrigerated storage base with doors |
| UCR-2 | Refrigerated storage base - Units 74" and longer |
